LogiLogic

LogiLogic is an offline digital logic gate simulator and Boolean algebra learning platform designed for computer science students, engineering enthusiasts, and educators.

Build, test, and analyze logic circuits directly on an intuitive interactive canvas. Connect input terminals, place logic gates, and observe real-time signal propagation through illuminated wire connections.

Key Features:

Interactive Workspace: Drag and drop digital components including AND, OR, XOR, NOT, NAND, and NOR gates onto a dynamic grid canvas.

Intuitive Wiring: Easily connect component terminals using direct drag-and-drop wire paths.

Live Signal Simulation: Visual high (1) and low (0) signal states with glowing wire paths for real-time visual feedback.

Dynamic Truth Tables: Automatically generate live truth tables that update as circuit input nodes are toggled.

Circuit Validation: Verify circuit logic against expected logic behavior with visual schematics and output badges.

Customizable Preferences: Adjust wire high-state colors, toggle snap-to-grid alignment, and switch between IEEE and IEC logic symbol conventions.

100% Offline & Private: Built to operate entirely without internet access. No accounts, no data tracking, and no ads.

Whether learning basic logic gates or analyzing combinational circuits, LogiLogic provides an approachable sandbox for exploring digital electronics.
